Francisco Passenger Jeepney
VEHICLE SPECIFICATIONS:
Parameters:
Seats 22 seats (plus 8 standing)
Dimension (mm) 5990*1830*2420 (Interior height≤175)
Wheelbase(mm) 3380
Curb Weight (kg) 1600
Max. Load (kg) 3600
Max Speed (km/h) 90
Gradeability(%) 22% (12.41 degrees)
Driving Mileage (km) 250
Front & Rear Track (mm) 1733/1733
Powertrain:
Electric Motor & Controller Permanent magnet synchronous motor system
Max Power(kW) 70
Max Torque(N*m) 230
Battery Type Lithium Iron Phosphate
Battery Capacity (kWh) 41.86
Slow Charge Cycle (h) 5.5
Fast Charge Cycle (m) 1 hour (SOC: 30% to 90%)
Charging Port DC 360kW CCS2 Level 3 Fast Charging
Charging Input (V) 220
Chassis:
Tire 195/70R15LT
Number of Tires 4
Steering System Electrically assisted steering
Brake System Frum hydraulic brakes, dual-circuit hydraulic brakes, parking brakes, vacuum boosters
Front Axle & Suspension Independent Suspension
Rear Axle & Suspension Fully floating rear axle, leaf spring non-independent suspension, barrel hydraulic shock absorption
Exterior and Interior:
Body King of the Road Iconic Design steel frame, electrophoretic anti-rust treatment
Interior Net height of the interior is 1750mm with handrails and handgrabs installed on the roof
Windows Front electric left & right side windows
Ventilation Aircon Cooling and Heating
Front Windshield Automotive laminated glass
Front Wipers Automotive-grade dual-linkage wipers with windshield scrubber
Ceiling Monolithic high-strength composite thermal insulation
Drivers Seat Adjustable Leather Seat
Passenger Seats Class 2 Bench Type (11+11)
Floor Aluminum pattern non-slip flooring
Assist and Pull Rod High-strength steel, anti-rust and anti-slip treatment on the surface
Door Driver controlled electric folding door at the front right side
Rearview Mirrors Manually adjustable, foldable exterior mirror and large wide-angle endoscope
Lights Combined headlights, front turn signals, combined rear tail lights, side turn signals
Warning Signals Dual snail electric horns and reversing buzzer
Instrument Panel Full LCD instrument (including current, voltage, vehicle speed, mileage, power, light signal, gear signal, alarm signal, fault code, self-test help, historical record, etc.)
Safety Features:
Seatbelt Driver seat with 3-point seat belt & alarm
Fire extinguisher 2kg
Brake Lamp High Position Brake Lamp
Solid and Liquid Protection IP67 Rating (Water Proof up to 1 meter for up to 30mins)
Tires Sealant Equipped
Electronic Tire Inflator Equipped
Early Warning Device Equipped
